| Part Numbers | MFS-100 |
| Maximun Load | 100A |
| Fuse Size | 22x58mm |
| Fuse Type | gG(General purpose) |
| Teminal Capacity | 35mm ² |
| IP rating | IP40 |
| Standard | IEC 60269-2 60269-3 EN 61439-3 EN 60947-3 |
| Knockouts | 32+25mm top and bottom |
| Recommended torque settings | 2.5Nm for all terminals |
| Rated Current Ie | 100A |
| Rated Operating Voltage (Ue): | 230V 50Hz |
| Number of Poles | 1P+N |
| Finish | Powder Coated Matt |
Metal Fused Switches MFS-100
£30.00
100A Fused Switch in a Metal Enclosure, Comes Complete with 63A, 80A & 100A Fuses
Technical Information
Dimensions
Dimensions
Basic circuit diagram
Basic circuit diagram
